The scene view gets crowded once a scene holds many behaviors, colliders and tilemaps. A new eye button in the topbar opens a list of all placeable asset kinds, and each row has toggles for what the scene view draws for that kind. - The popup lists all 9 placeable kinds from Behavior to Tilemap, with the columns Symbol, Name and Shape. It stays open while switching. - Sprite, Text and Tilemap draw no symbol, so their symbol toggle is greyed out. Their name toggle shows a new centred name tag, which is off by default. - Shape exists for Collider and Tilemap. A hidden collider outline is neither drawn nor clickable. A hidden tilemap shape removes the collision outlines and the paint tint, the tiles stay visible. - A hidden symbol takes no slot in the ring and draws no dashed link to its parent. A name that stays on moves to the centre of the object. - The setting lives in the project as `sceneVisibility`, not in localStorage. Older projects load with the defaults, which match the view as it was. - Switching has no undo step, like the game scale. It only changes the view. A change made during Play survives Stop. - The rules sit in `src/core/model/sceneVisibility.ts`, the popup in `src/editor/panels/SceneVisibilityPopup.ts`. Four new SVG icons. Not covered by a check: symbol off with name on for a kind with a symbol, Text and Tilemap with names, and the paint tint with shape off. Tests: - ./check.sh: 173 files, 2515 tests, CHECK EXIT 0 - e2e 46: ALL PASSED, 17 checks. 46g clicks the popup, lays a small tilemap over the crate and removes it again. - e2e 8 alone on a fresh seed: ALL PASSED, 23 checks. A red check in the partial run 2,8,46 came from the module selection. - 8 new unit tests in tests/editor/scene-visibility.test.ts. - 4 counter-probes, each fails its test: load ignores the saved value, Play skips the saved model, scene view ignores collider shape, scene view ignores tilemap shape. Co-Authored-By: Claude Opus 5.5 <noreply@anthropic.com>
Game Maker
A browser-based tool "one step before a game engine": create assets (scenes, cameras, sprites), place them into scenes, tweak their properties in an inspector and press Play – all in one program, all drawn inside a single WebGL canvas.
Live: https://nockal.com/game-maker/ · Widget playground: https://nockal.com/game-maker/?playground
The documentation is the wiki: https://git.nockal.com/meleki/game-maker/wiki – every concept, node, tab and shortcut, plus the architecture and the development workflow. This file is the short way in.
In one screen
- An asset is a named, typed thing (scene, camera, sprite, text, behavior, collider, rigidbody, container, texture, vector art, pixel art, palette, font, sound, animation, state machine, shader, particles, variables, tile, tilemap) with properties and no position.
- A scene object places an asset: position, sparse overrides of its properties, an optional parent. Only what differs from the asset is stored; the inspector paints it gold and offers ↺ / ↑.
- A container is a reusable group edited once and placed many times; its content is resolved from the template on every read. A screen is a container switched on and off.
- A behavior is logic as a node graph, placed like anything else and parented to the object it acts on. Play has no built-in behaviour – everything that happens is a graph.
- An account owns projects: the editor asks for a user name and a password first, and each account sees only its own projects. The Account menu at the far right of the toolbar changes the password and signs out.
- Play runs a throwaway copy of the project; every panel stays usable and Stop brings back exactly what was saved.
Quick start
Node 22 is required.
npm install
npm run dev # http://localhost:5175/game-maker/dist/ – API calls are proxied to production
npm run check # typecheck + lint + format:check + unit tests – the gate CI runs too
npm run build # writes dist/ and regenerates index.html; the folder is what nginx serves
The browser suite and the three example games need a machine with a GPU:
node tools/seed-e2e.mjs && node tools/e2e.mjs # the editor, 1422 checks (GM_STEPS=20 for one step)
# every tool signs in first – see the Accounts page
node tools/seed-jumprun.mjs && node tools/smoke-jumprun.mjs
node tools/seed-tetris.mjs && node tools/smoke-tetris.mjs
node tools/seed-actor.mjs && node tools/smoke-actor.mjs
Every push runs all of it on the Gitea runner – the gate as one job, build and suite as another beside it – so locally take the gate plus the step your change touches and leave the full run to CI. Details, the GPU requirement and the detached runner are in Development.
Documentation
| Page | What it covers |
|---|---|
| Concepts | Assets, scene objects, overrides, play mode, the camera, the console |
| Accounts | Signing in and out, the accounts, who a project belongs to, what the check tools need |
| Scenes | The edited scene, the start scene, and switching scenes from a graph |
| Scene editing | Placing, z-order, hierarchy, the editor offset |
| Behaviors | Node graphs: variables, the node set, structs and lists, loops, nesting, editing |
| Colliders | Shapes (box, circle, capsule, polygon), collision events, blocking movement, one-way colliders and raycasts |
| Physics | Rigidbodies, the collider material, gravity, the fixed step |
| Textures | Images, frames, nine-slice, the filter, upload limits |
| Vector art | Pictures drawn from shapes: the pen, curves, gradients and texture fills, combining shapes |
| Pixel art | Pictures painted pixel by pixel: the palette, the tools, layers and frames |
| Fonts | Font assets, the picker, what a text falls back to |
| Sounds | Sound assets and Play sound |
| Animations | Animation assets and the Animation tab |
| Shaders | Shader graphs a sprite wears, their node set, the properties they declare |
| Particles | Particle graphs: a particle as a function of its age |
| State machines | The asset, named transitions, State branch, Set state and State transition |
| Containers | Templates, instances, screens |
| Tiles | The tile asset, plain tiles and the two autotile kinds, the pictures as animation steps, the Tile tab |
| Tilemaps | The tilemap asset, painting in the scene view, layers, what it looks like in the game |
| Plugins | Extending the editor: the plugin file, how it is loaded, switching one on and off, API v1 |
| Keyboard | Every shortcut |
| Architecture | Stack, source layout, the rules that keep it organised |
| Development | Commands, the e2e suite, the example games, CI |
| API | The PHP JSON API and the project document |
Ideas, gaps and bugs
They live in the issue tracker: https://git.nockal.com/meleki/game-maker/issues. What is not there yet is listed on the wiki's Home page.
